Obtentu U/UTP CAT.5E Antibacterial Patch Funiculus

Nos enucleavimus panni rudis antibacterial. Funem & plug & fingunt cum specialibus materiis. Actio antimicrobialis obtemperat cum ISO 22196:2011. Praesertim haec antibacterial panni funiculus valetudinarium & deversorium & etc.

Antimicrobialis actio prosequitur ISO 22196:2011

Sequere ANSI/TIA-568.2-D & ISO/IEC 11801

Cat.5E lacus funis cum C% continuatio Test. (Component Test libitum)

Nuda Cuprum cum Stabilius euismod

50U" Aurum Plating RJ45 Plugs with Patented Design

Variis coloribus & CUMATIUM Available

Coitus Cycles: Sursum ad MCC tempora

Apta 4PPoE (IEEE802.3bt/IEC60512-99-002) Applications

Operatio Temperature Range: -10~60

UL / ETL / DELTA / 4PPoE / CE Certified & obtemperare cum RoHS & SPATIUM

Serva Healthy & Tutus!

Nobis loquere Add to Part List

PREV PRODUCT：F/UTP CAT.5E Antibacterial Patch Funiculus
NEXT PRODUCT：The read operation timed out

EXW Patch Funiculi occurrentes signa:

ISO/IEC 11801:2011

ANSI/TIA-568.2-D

ANSI/TIA-1096-A (FCC Part 68)

EN50173-1:2011

UL 444

● 4PPoE (IEEE802.3bt / IEC60512-99-002) Applications

• EXW Part No

5EUTXXAntibacterial : Cat.5E U/UTP Resracto circa Antibacterial Patch Funiculus, PVC/LSOH/TPE/PUR

• Quality Assurance

100% Continuitas Test (Component Test Libitum)

• Testimonium

UL/ETL/DELTA/4PPoE/CE Certified & obsequi cum RoHS & SPATIUM

• Applicationem

* Aer Networking

* Computer Networking Project

* Audio & Data Transmissio

* Digital Networking

* Broadband Networking Communication

• EXW Standard Color Code

• Latin Rate Package

Longitudo (M)	Cat.SE UTP (pcs)	N.W(KG)	G.W(KG)	Ratio stipare	Lobortis Size
0.5	300	7.48	8.48	1pc / blank peram cum pittacium	400375 290MM(0.0435CBM)
1	200	8.25	9.25
2	120	9.12	10.12
3	100	11.31	12.31
5	60	10.01	11.01
10	40	13.01	14.01
15	25	12.08	13.08
20	20	13.59	14.59

Filum Color Code

album - caeruleum / caeruleum

album - orange / orange

album - viridis / viridis

album - brunneis / brunneis

• Component

Conductor:	AWG 24 (Destradatum Cuprum 7x 0.2mm), 4-Pair ,8C
Insulatores:	PE
Insulatio Diameter:	0.97 ± 0.05mm
Nom. Crassitudo;	0.18mm
Jacket:	PVC/LSOH/TPE/PUR
Jacket Diameter:	5.5 ± 0.2mm

• Electrical Characteres

DEINDE Necessitas:	margo 1dB comparatur ANSI/TIA-568.2-D
Revertere damnum opus est:	margo 1dB comparatur ANSI/TIA-568.2-D
Current Rating:	1.5 A
Resistentia Nulla:	100 MΩ min
Contactus Resistentia:	20 mΩ max
Fortitudo dieelectric:	500 VAC(rmat)
Voltage:	72 VDC max

• Mechanica characteres

Vitae insertio:	cyclos admissura DCCL
Installation Temperature:	0/50℃
Operatio & Repono Temperature:	-20/60℃
Cable ad plug tensile virtus:	20pound(min)
Vis trahens:	10N(max)
