Arcum munitum Cat.6A Claustrum Connector

EXW qualitas princeps Cat.6A RJ45 8P8C STP Arcus Modularis Plugs ex materia rudis importata factae sunt.

Obsequio cum ISO/IEC 11801-1 & ANSI/TIA-568.2-D

● Follow IEC 60603-7 series for RJ45 8-way Connector

Meet FCC Standard

CAT.6A / CAT.6 / CAT.5E Arch Plug Available

● Diversum Aurum Crassitudo Available (50u", 30u", 15u", 6u", 3u", mico)

Coitus Cycles: Sursum ad MCC tempora

Apta pro 4PPoE (IEEE802.3bt/IEC60512-99-002) Applications

●Cable Wire Cange: 24AWG ad 26AWG

UL / POE / CE Certified & obsequi cum RoHS & REACH

Cum Special Designed Booz

Unumquodque obturaculum modularis inspicitur ab AOI apparatus (Optica Inspectionis Automatica) ad qualitatem praestandam. Lineas productionis plenae habemus cum plumbeo flexibili.

Grata OEM/ODM. EXW est optimus choice!

Nobis loquere Add to Part List

PREV PRODUCT：No previous article
NEXT PRODUCT：Obtentu Cat.6A Arcus Claustrum Modular Plug

Features:

Obsequor ANSI/TIA-568.2-D & ISO/IEC 11801

Apta pro 4PPoE (IEEE802.3bt/IEC60512-99-002) Applications

Obsequio requisitis ANSI/TIA-1096-A (FCC Part 68)

● Comply with IEC 60603-7 series for RJ45 8-way connector

Parere cum UL 186

• Part No

C6R5Z50V2IL-3R : Cat.6A UTP Arcus obturaculum modularis ad Cat.6A Solidum & stratum UTP fune lan.

C6R5Z50V2SIL-3R : Cat.6A STP Obturaculum modularis Arch designatum pro Cat.6A Solidum & subductis UTP cables lan.

• Quality Assurance

Unumquodque obturaculum modularis inspicitur ab AOI apparatus (Optica Inspectionis Automatica) ad qualitatem praestandam.

• Testimonium

UL/4PPoE Certified & obsequi cum RoHS & SPATIUM

• Applicationem

Restrictius postulationi LAN occurrendum et in frequentiis altis usque ad 500MHz constantem impedimentum sustine.

• Diversus color Available

• Sarcina Latin Rate

Spec.	Stipare Rate (PCs)	N.W(KG)	G.W(KG)	Ratio stipare	Lobortis Size
Cat.6A STP Plug	10,000	23.50	24.80	1,000pcs/blank sacculi 2 interiores greges/Carton	516* 362*320MM(0.06CBM)

• Electrical Characteres

UL Applicatio:	250 Valts AC max, AT AMP
Dieelectrica intentione obstantibus:	500 Volts AC
Resistentia Nulla:	100MΩ
Terminatio:	Resistentia 20MΩ max post environmental probatio.

• Mechanica characteres

Vitae insertio:	cyclos admissura DCCL
Installation Temperature :	0/50℃
Operation & Repono Temperature :	-20/60℃
Cable ad plug tensile virtus:	20pound(min)
Vis trahens:	10N(max)

•Component

habitationem:	Polycarbonate, UL94V-2 or UL94V-0
Aurum Plating:	50u", 30u", 15u", 6u", 3u" vel flash
Contactus laminae:	Aeris Alloy
Contactus:	Filum solidum vel straded, ex 24 AWG ad 26AWG
Color:	Transparens vel alius color
